Made in USA
Orem, Utah
Lifetime Guarantee
Unconditional
10 Colors
In-house powder coat
Fully Adjustable
0-6" of lift
3 X-Series Options
Only Core 4x4
The Special Sauce:
HOUSING
- SAE 1045 Solid Steel Forged Housing: This is unequivocally the best carbon alloy steel for this application.
- CNC Machined Housing: Make our parts and bearings dimensionally perfect, eliminating any die wear issues.
BALL STUDS
- SAE 4140 hot forged Chromoly Ball Studs: For strongest possible metallurgy.
- Induction Heat Treated Ball Studs: Provides a very precise heat treatment to the exact depth and location we want it.
- Rolled Threads: Are made by pressing the shape of the threads into the ball stud instead of cutting. This strengthens the threads instead of weakening them and allows for easy movement of hardware. This ain't no Ikea furniture!
- Step Threads: Allow for very easy movement of hardware on install and superior holding when torqued. (installer choice).
BEARING DESIGN
- Rugged Metal to Metal Bearing.
BOOTS
- CR Rubber Boots: The most durable material for undercar applications. Resistant to deterioration from road level ozone, oil/gas/engine fluids and extreme heat or cold
- Accordion Boot: ideal for high-articulation components, more flexibility means longer life.
HARDWARE
- Grade 8 - Class 10.9 Hardware: Superior tensile strength.
- Castle Nut: Industry standard where high vibration loads occur.
LUBRICATION
- Pre-threaded Zerk Housing: If you have ever installed a MOOG Ball Joint without a pre-threaded zerk fitting you will understand what a simple but great feature this is. Another installer fav.
- Greaseable: Because it should be.
- Pre-Greased: Just in case you forget, we have you covered.
- Gull Winged Grease Grooves: Allows for improved lubrication disbursement around the ball stud.
- Zerk Fittings: Included for every application.
| Make | Model | Submodel | Years |
|---|---|---|---|
| Jeep | Gladiator | 2020 - Present | |
| Jeep | Wrangler | 2018 - Present |
| Vehicle | Jeep Gladiator JT (20–Present) or Jeep Wrangler JL / JLU (18–Present) |
| Brand | Apex Chassis |
Reviews of Core 4x4
5.0
★
★
★
★
★
132 reviews
VK
Victor Keele
Sep 24, 2025
★
★
★
★
★
Great customer service. I got my front upper and lower control arms and hardware on Friday afternoon. It didn’t come with instructions so I called Core 4X4 and they immediately e mailed me the instructions. Also, the kit I got had the spacers missing so I called. It was late Friday by thus time but they took care of the issue first thing Monday morning and I got the spacers on Tuesday. Great company.
J
Justin
Mar 24, 2021
★
★
★
★
★
Small business, family owned, made in the USA, lifetime warranty. Purchased Tier 3 control arms and rear track bar for a 2006 Jeep LJ. Simple website and easy to contact over phone and email. I had some technical questions and they were happy to answer them. They allow local pickup and were built to order same week. The order was wrapped and ready when I walked in and even gave a tour of the shop. They abrasive blast all raw materials to achieve a better surface profile for powdercoat to adhere and create a smooth, durable finish. I also noticed several CNC machines and a robotic welder they use for all their parts. A small outfit with a robotic welder? Their concern for quality is obvious and it shows in the parts they make. Very impressed. Happy to do business with these guys.
DA
Dastrup Auto
Mar 25, 2019
★
★
★
★
★
I have bought a bunch of sets of arms, track bars and even had custom work done by Core 4x4. Just yesterday, Spence and Cam delivered an awesome cross member they designed and built for me! All of their products have been exceptional! I have personally seen their progression with design changes/updates. They truly take pride in their work and products. Quality control is second to none! They’ve also helped me diagnose issues with different jeeps I’ve had, as well as Dodge/Rams. These guys know their stuff! Really! I trust them whole heartedly and absolutely love their products/quality of work! I’ve referred many people, and will always continue to do so. Keep up the good work Core4x4!
NP
Norb Pranger
Oct 24, 2025
★
★
★
★
★
Not sure where to start, Products or Service or Warranty.
Products: I found Core4x4 through a very respected YouTuber in the Jeeping community. I purchased an entire set of Core4x4 Control Arms three years ago and have beat the daylights out of them and they are still in great condition. Now, I purchased another Jeep, this time for my daughter and bought yet another set of Control Arms because I know that these things can take a beating and stand up to it. I plan on replacing more parts on this TJ and my JL and will continue to buy from Core4x4.
Service: This isn't some huge name conglomerate that treats you like you're just another customer. They are quick with responses and will always make things right should something be a problem. Oh and the quickness in which they ship their products is unmatched. I bought these CAs for my TJ on Thursday, I received them on Monday. Most other manufacturers will tell you weeks, they had them to me in 2 shipping days.
Warranty: Seriously, a lifetime warranty? Yes please. Nothing more to say.
I can't say enough about how great of a company this is. I've even spoken to the owner through email a few years back on some questions that I had. Support small American built businesses.
P.S. Core 4x4, feel free to make me an ambassador and send me some swag :) .
TR
Tim Reigies
Mar 25, 2018
★
★
★
★
★
Received the track bar I ordered, product looks extremely strong, thx core 4x4
A
Adam
Oct 24, 2025
★
★
★
★
★
I couldn't have been more excited for the initial unboxing of these new Core 4x4 UCA's!
They appear to be so well built and just a true quality product.
Installation was a breeze and the initial testing with the forklift appears to have given me some additional flex with less binding on the rest of the components now that the geometry is back properly aligned.
Time will tell how they hold up on my near future off-road adventures but I don't have any doubt that they are up to the task!
MH
mark hinz
Mar 2, 2026
★
★
★
★
★
Went above and beyond to get the parts we needed to complete our customers build for Moab Easter safari cant thank you enough for all your hard work and efforts
Thank you and look forward to working with you in the near future
DS
Dana Smith
Jul 26, 2025
★
★
★
★
★
Excellent, strong, and durable products—perfect for both on-road and off-road applications. The customer service is outstanding—friendly, knowledgeable, and extremely helpful with understanding installation and ensuring I got exactly what I needed. I would definitely order again. Top-notch company with high-quality products made right here in the U.S.A.
RP
Robin Poole
Jul 26, 2025
★
★
★
★
★
I had several questions before my purchase and Korby helped me with the correct parts to order and recommendations. Outstanding customer service and product knowledge! Can't wait to install them!
TG
Travis Grimm
Mar 23, 2024
★
★
★
★
★
To start off if you're looking to upgrade your control arms definitely hit this company up. Great product, easy install of the product, with three different tiers everything is priced pretty good, I'm a sticker guy and they sent a sticker for each arm each track bar and also three extra ones so the extra are on the Jeep the advertise them for sure. If you're reading this review I highly recommend you to check their website out.
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Specifications
| Vehicle | Jeep Gladiator JT (20–Present), Jeep Wrangler JL / JLU (18–Present) |
| Brand | Apex Chassis |
