Made in USA
Orem, Utah
Lifetime Guarantee
Unconditional
10 Colors
In-house powder coat
Fully Adjustable
0-6" of lift
3 X-Series Options
Only Core 4x4
The Special Sauce:
HOUSING
- SAE 1045 Solid Steel Forged Housing: This is unequivocally the best carbon alloy steel for this application.
- CNC Machined Housing: Make our parts and bearings dimensionally perfect, eliminating any die wear issues.
BALL STUDS
- SAE 4140 hot forged Chromoly Ball Studs: For strongest possible metallurgy.
- Induction Heat Treated Ball Studs: Provides a very precise heat treatment to the exact depth and location we want it.
- Rolled Threads:Are made by pressing the shape of the threads into the ball stud instead of cutting. This strengthens the threads instead of weakening them and allows for easy movement of hardware. This ain't no Ikea furniture!
- Step Threads: Allows for very easy movement of hardware on install and superior holding when torqued. (Installer Choice).
BOOTS
- CR Rubber Boots: The most durable material for undercar applications. Resistant to deterioration from road level ozone, oil/gas/engine fluids and extreme heat or cold
- Accordion Boot: ideal for high-articulation components, more flexibility means longer life.
FINISH
- E-Coating: Extremely durable electrochemical finishing process
HARDWARE
- Grade 8 - Class 10.9 Hardware: Superior tensile strength.
- Castle Nut: Industry standard where high vibration loads occur.
LUBRICATION
- Pre-threaded Zerk Housing: If you have ever installed a MOOG Ball Joint without a pre-threaded zerk fitting you will understand what a simple but great feature this is. Another installer fav.
- Greaseable: Because it should be.
- Pre-Greased: Just in case you forget, we have you covered.
- Gull Winged Grease Grooves: Allows for improved lubrication disbursement around the ball stud.
- Zerk Fittings: Included for every application.
SPECIAL FEATURES
- Minimum Engagement Mark on Drag Link End Threads: If this mark in the thread of the drag link is showing it means you are beyond the safe engagement of threads into the adjusting sleeve. You may be lifted too high and need to switch to a flip kit or you may need to equal out the adjusting sleeve between the two ends.
| Make | Model | Submodel | Years |
|---|---|---|---|
| Jeep | Wrangler | 2007 - 2018 |
| Brand | Apex Chassis |
Reviews of Core 4x4
5.0
★
★
★
★
★
132 reviews
JF
jacob fezza
Mar 24, 2022
★
★
★
★
★
I wanted to take a moment and give these guys a shout out, I’ve currently got, for my xj, their adjustable control arms, tier 4 adjustable track bar and adjustable leaf spring shackles. You can always count on a fair price, high quality products, and quick delivery. Keep up the great work guys, will definitely continue to shop with you
N
Nick
Sep 24, 2025
★
★
★
★
★
I have a 2016 RAM 1500 Crew Cab and I replaced the rear upper and lower control arms also the pan hard track bar and also the sway bar and links for the rear with all I had the articulating bushings. The vehicle now has no body role. They are absolutely incredible if you get the control arms you gotta get the CORE 4 x 4sway bar end links don’t don’t try and be cheap and get Moog or something else you got to get articulating bushings get the core 4 x 4 ones they are the best. My truck drives now through the canyons like a BMW. I have Fox high-performance shocks on there as well with all the CORE 4 x 4 suspension parts and they are amazing. Well worth the money I would highly recommend anybody thinking about CORE 4 x 4 go with CORE 4X4 and if you can go with their articulating bushings, they’re unbelievable drives better now than my Escalades. Well planted no body role and smooth on the Highway unbelievable the difference they all made!!
THANKS AGAIN CORE 4x4!!!!
CL
Colten Lockwood
Mar 25, 2019
★
★
★
★
★
Recieved warrenty exchanges for my control arms last night couldnt be happier!!! Lets talk about the arms tho! Great quality arms in multiple styles and colors!!! I purchased the teir 3 short arns for my 98 xj. I can say that they setoff nicely so my 35 inch tires do not rub! As long as you can get a photo or video of broken hardware core will take care of you. The body of the arm is bulletproof. However make sure to maintain and grease the joints regularly as with any greaseable joint and they shouldkast forever. I had a few problems arise a year after purchase and after some troubleshooting spence was able to help get me the correct parts to get back on the road. I recommend this setup to any and all jeepers looking to get away from the stock arm setup. Alltogether i am Very happy with the performace of my control arms!!!! Mechanic and bodyman of 12 years and my first choice for quality control arms!!
J
Justin
Mar 24, 2021
★
★
★
★
★
Small business, family owned, made in the USA, lifetime warranty. Purchased Tier 3 control arms and rear track bar for a 2006 Jeep LJ. Simple website and easy to contact over phone and email. I had some technical questions and they were happy to answer them. They allow local pickup and were built to order same week. The order was wrapped and ready when I walked in and even gave a tour of the shop. They abrasive blast all raw materials to achieve a better surface profile for powdercoat to adhere and create a smooth, durable finish. I also noticed several CNC machines and a robotic welder they use for all their parts. A small outfit with a robotic welder? Their concern for quality is obvious and it shows in the parts they make. Very impressed. Happy to do business with these guys.
JA
Jonathan Aguilera
Jan 22, 2026
★
★
★
★
★
Great experience with Core 4x4! I purchased some suspension parts for my dad's 98 Jeep TJ. The products they make are super durable and look even better in person. Attention to detail and overall superior quality. The staff at Core 4x4 is super helpful also, Korby has been great. Updating me on the status of my order and sending me tracking numbers as well. Thank you all at Core 4x4, keep up the amazing work!
RM
R2d2 Movi78
Feb 21, 2026
★
★
★
★
★
I’m extremely impressed with Core 4x4. The quality of their parts is outstanding — everything feels solid, well‑built, and engineered with real attention to detail. Shipping was fast and everything arrived perfectly packaged. Their customer service is just as good as their products: responsive, helpful, and genuinely committed to making sure you get exactly what you need.
Overall, a top‑tier experience. I’ll definitely be buying from them again. Specially thank you Mr. Linscomb from Core 4x4. Arturo M.
JL
John Luna
Nov 23, 2025
★
★
★
★
★
Great team, and help to support my jeep and provide best stuffs
CL
Cade Leith
Mar 23, 2024
★
★
★
★
★
Have full upper/lower CA set on both front and rear axles on a 96 ZJ. These are the rubber bushing sets not joint sets. I have beat the hell out it in the Nevada desert for 2 years and has been great. I don’t go fast but I do articulate suspension a lot. Super solid and haven’t any issues. Just inspected the entire set recently due to some banging under it. Turns out the banging is lower rear shock bushings. Inspected each CA along the way nothing. Aside from dirt and obviously winter roads and what not still in excellent condition, bushings are solid like the day they were installed. I’ll add that I’m about tapped on a short arm at 4.25(less with settle) so the front CA’s get beat on just from that, still they’re like new. Paint is great condition, this set is red. I would definitely buy again. Another plus for me, Utah isn’t local necessarily, but it’s nice to support businesses closer to me.
JW
Jonathan Word
Aug 25, 2025
★
★
★
★
★
Beefy parts made and painted well, very fair pricing for what you get, and fantastic customer service to boot. Easily my favorite place to get suspension parts.
MG
Morgan Griffith
Mar 25, 2018
★
★
★
★
★
I met a couple of the Core 4x4 guys at the Salt Lake Offroad Expo and decided to try them out after noticing one of my control arm bushings was disintegrated. I called to discuss parts on Thursday and I was leaving for a trip on Saturday. These guys built my control arms and had them ready to be picked up Friday, 24 hours later. The parts seem to be great quality and they charged me nothing extra to have them painted. These guys were extremely helpful and without them my trip probably would have been cancelled. looking forward to testing out the arms on my next trip to Moab.
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Specifications
| Brand | Apex Chassis |
