Made in USA
Orem, Utah
Lifetime Guarantee
Unconditional
10 Colors
In-house powder coat
Fully Adjustable
0-6" of lift
3 X-Series Options
Only Core 4x4
The Special Sauce:
HOUSING
- SAE 1045 Solid Steel Forged Housing: This is unequivocally the best carbon alloy steel for this application.
- CNC Machined Housing: Make our parts and bearings dimensionally perfect, eliminating any die wear issues.
BALL STUDS
- SAE 4140 hot forged Chromoly Ball Studs: For strongest possible metallurgy.
- Induction Heat Treated Ball Studs: Provides a very precise heat treatment to the exact depth and location we want it.
- Rolled Threads:Are made by pressing the shape of the threads into the ball stud instead of cutting. This strengthens the threads instead of weakening them and allows for easy movement of hardware. This ain't no Ikea furniture!
- Step Threads: Allows for very easy movement of hardware on install and superior holding when torqued. (Installer Choice).
BOOTS
- CR Rubber Boots: The most durable material for undercar applications. Resistant to deterioration from road level ozone, oil/gas/engine fluids and extreme heat or cold
- Accordion Boot: ideal for high-articulation components, more flexibility means longer life.
FINISH
- E-Coating: Extremely durable electrochemical finishing process
HARDWARE
- Grade 8 - Class 10.9 Hardware: Superior tensile strength.
- Castle Nut: Industry standard where high vibration loads occur.
LUBRICATION
- Pre-threaded Zerk Housing: If you have ever installed a MOOG Ball Joint without a pre-threaded zerk fitting you will understand what a simple but great feature this is. Another installer fav.
- Greaseable: Because it should be.
- Pre-Greased: Just in case you forget, we have you covered.
- Gull Winged Grease Grooves: Allows for improved lubrication disbursement around the ball stud.
- Zerk Fittings: Included for every application.
SPECIAL FEATURES
- Minimum Engagement Mark on Drag Link End Threads: If this mark in the thread of the drag link is showing it means you are beyond the safe engagement of threads into the adjusting sleeve. You may be lifted too high and need to switch to a flip kit or you may need to equal out the adjusting sleeve between the two ends.
| Make | Model | Submodel | Years |
|---|---|---|---|
| Jeep | Wrangler | 2007 - 2018 |
| Brand | Apex Chassis |
Reviews of Core 4x4
5.0
★
★
★
★
★
132 reviews
JC
John Cutler
Oct 24, 2025
★
★
★
★
★
In September 2025, we visited CORE 4x4 in Orem, Utah. CORE 4x4 makes control arms and other similar parts that stiffen the suspension of an off-road 4x4 vehicles, so that the off-road vehicles can travel on more rugged terrain. CORE 4x4 used to share this building with another business, and since this other business has moved elsewhere, CORE 4x4 will continue to expand and grow their business. Good for CORE 4x4 to be a growing company and to expand into the vacant part of the building.
GV
Gil Valk
Sep 24, 2025
★
★
★
★
★
Excellent service, Prompt responses when needing technical assistance, Amazing looking parts that fit excellently. I would recommend them to anyone looking for suspension components. Also very well packaged when we received the shipment, which means no damage from shipping company!! We went with the Crawl Series double adjustable kit and it definitely looks killer on our build!!!
SG
Sal Giordano
Sep 24, 2025
★
★
★
★
★
I want to take the time to share my experience with Core 4x4.
I have a 2004 Jeep Wrangler and was looking to upgrade some suspension parts. I went with Core 4x4 upper & lower adjustable control arms and a front adjustable track bar. Everything arrived quickly, and right out of the box I was impressed with the quality and craftsmanship.
I had a few questions during installation (measurements and torque specs), and I spoke with Korby on a couple of occasions. Not only did he send me detailed instructions, but he also shared an installation video specific to the part and vehicle I was working on, something you don’t get from many companies.
The control arms fit perfectly, look great, and perform exactly as I hoped. I did run into an issue with the front track bar touching the front diff. When I reached out, Korby had me send pictures and then immediately offered two solutions: his bar guy could make a different bend and send it out to me, or I could get a full refund. His response honestly blew me away. As much as I wanted to run the Core 4x4 track bar, I chose the refund. Korby sent me a prepaid shipping label right away, no hassle.
My experience with Core 4x4 has been excellent. Korby was extremely understanding, communicative, and helpful every step of the way. The parts I received were high quality, and the customer service was second to none.
I would absolutely recommend Core 4x4 10 out of 10 times and will be using them again. Just a great American company with awesome people who truly care about their customers.
Thank you Korby, and thank you Core 4x4!
MG
Morgan Griffith
Mar 25, 2018
★
★
★
★
★
I met a couple of the Core 4x4 guys at the Salt Lake Offroad Expo and decided to try them out after noticing one of my control arm bushings was disintegrated. I called to discuss parts on Thursday and I was leaving for a trip on Saturday. These guys built my control arms and had them ready to be picked up Friday, 24 hours later. The parts seem to be great quality and they charged me nothing extra to have them painted. These guys were extremely helpful and without them my trip probably would have been cancelled. looking forward to testing out the arms on my next trip to Moab.
N
niceguyr1
Mar 24, 2023
★
★
★
★
★
I purchased upper and lower adjustable arms for my WJ and lowers were missing the spacers. I didn't know until 3 months later when I was installing them. With absolutely zero hassles they quickly sent me the missing spacers. Fantastic product and service! Huge thank you guys for the awesome service and parts!!! Customer service is quickly becoming a lost commodity and you guys gave me hope that it's still alive and well, you just have to buy from the right people... Thanks again for going above and beyond! 👍👍
OJ
Oldgreg jr
Mar 23, 2025
★
★
★
★
★
Good company, they offer well built parts and Great customer service.
I had a couple of hang ups with my control arms that I purchased, they were very easy to work with and found the solution to make them work.
KK
Kevin Kinard
Oct 24, 2025
★
★
★
★
★
Great product, excellent customer service. I mistakingly ordered a track bar for the wrong year model and Korby helped me out by sending me the correct part that I needed no questions asked. I highly recommend.
CM
Craig MacIver
May 27, 2025
★
★
★
★
★
Got the CAMP version of adjustable control arms and track bars for our 03 TJ with a 3” lift and 33x10.5 KO 2’s.
Super beefy bars, great fit and adjustability.
Friendly advice and support from Korby at CORE 4X4. Good follow up as well.
The ride quality is great as well as the handling. I think it all looks pretty good as well.
JA
Jonathan Aguilera
Jan 22, 2026
★
★
★
★
★
Great experience with Core 4x4! I purchased some suspension parts for my dad's 98 Jeep TJ. The products they make are super durable and look even better in person. Attention to detail and overall superior quality. The staff at Core 4x4 is super helpful also, Korby has been great. Updating me on the status of my order and sending me tracking numbers as well. Thank you all at Core 4x4, keep up the amazing work!
MN
Mike Nielsen
Nov 23, 2025
★
★
★
★
★
The customer service is first class. I had an issue with a track bar I installed on my F350. I don’t have any other Core 4x4 parts yet, but with the way I was treated, I know their parts are well done, because they went above and beyond to make sure I was made whole. They wouldn’t be in business if they had to take care of a lot of people like they took care of me. Will definitely be back when it’s time to build the Jeep!
Your Dynamic Snippet will be displayed here...
This message is displayed because youy did not provide both a filter and a template to use.
Specifications
| Brand | Apex Chassis |
